Cygnet Stainless™ is committed to offering the the highest quality products with the best customer service to the stone fabrication and kitchen and bath industries. Cygnet provides the following links to download DXF files and PDF diagrams for the Evolution Series sinks in one folder. Our stainless sinks have an 1/8″ reveal. Due to the difference in CAD/CAM workflow and fabricator preference, Cygnet cannot accept responsibility for the finished cutout. Please check the files carefully to ensure that the cutout suits your needs.
By downloading these files you certify that you have read the above statement and understand fully.
- 304 18/10 scratch resistant commercial grade stainless steel with premium brushed satin finish
- Hybrid construction. Stronger and heavier than comparable 16-gauge sinks.
- Not pressed or stretched.
- Center-set 3 1/2″ drain opening.
- Padded and undercoated insulation minimizes noise.
- Corner radius: 3/4″
- Mounting hardware and cutout template are included.
- SGS compliant (U.S.) & CSA certified (U.S. & Canada).
Frequently Asked Questions
Still have questions? Send us your question by filling out the form below, or give us a call during business hours. We will be happy to assist you.
Where can I access cutout files and PDF diagrams?
The downloads for the DXF files and PDF diagrams are below.
How much reveal does the Evolution Series have?
Our stainless sinks have an 1/8″ reveal.
